How Data Stored In a CD


Abstract
You can fit on a S/VCD without over burning:
- approx. 735 MB of MPEG data onto a 74min/650MB disc
- approx. 795 MB of MPEG data onto an 80min/700MB disc
You can fit on a CD-ROM without over burning:
- approx. 650 MB of data onto a 74min/650MB disc
- approx. 703 MB of data onto an 80min/700MB disc

Introduction
Let us ignore for now the terms of megabyte for CD capacity and try to understand how the data is stored on a CD.
As well all know, the data is stored digitally as binary data. This means, however the actual information is actually kept on the disc, this information is in the form of "1"s and "0"s. Physically, the information on a CD is as pits on a thin sheet of metal (aluminum).
An a CD-R disc, the data is physically on an organic dye layer which simulates the metal layer on a real pressed CD.
Verbatim 94554 700 MB 52x 80 Minute Branded Recordable Disc CD-R, 100-Disc SpindleAmazonBasics 700MB 52x CD-R (100-Pack Spindle)100 SONY CD-R Music Disc, Digital Audio Recordable For CD Recorders and Computer Writer, 5 Assorted Color, 80 minMemorex 50-pack Slim CD/DVD Jewel Cases (5mm) Clear

How is the information structured
Now, on the CD, the information isn't just organized from beginning to end willy-nilly. Otherwise, it would be really hard to find a useful piece of information on the CD.
Rather, the information is organized in sectors. Consider a sector as like a page in a book. Just like you are able to quickly find something in a book if you know the page number, you can quickly find something on a CD if you know the sector number.
Now, remember that the CD was original made to hold audio data. It was decided, that the CD would would 75 sectors per second of audio. Although I cannot guess where this number comes from, it is quite appropriate for the audio CD. It means that you can "seek" an audio CD accurately to 1/75th of a second -- which is more than enough for consumer purposes.
Now, with this in mind, we can work out the total data capacity of user data for 1 sector.
C D
The total data capacity of user data of 1 sector on a CD
CD audio uses uncompressed PCM stereo audio, 16-bit resolution sampled at 44.1 kHz.
Thus 1 second of audio contains:
16 bits/channel * 2 channels * 44100 samples/second * 1 second
= 1411200 bits
= 176400 bytes
Since there are 75 sectors per second
1 sector
= 176400 bytes / 75
= 2352 bytes
One sector on a CD contains 2352 bytes max.
----------------------------------------------------------------
The concept of different MODES and FORMS of burning
Now, audio CD was well and good, but the medium would become much more useful if you could store other data on the disc as well. This became to be know as CD-ROM of course.
Now, the audio-CD uses the ENTIRE sector for audio data.
However, for CD-ROMs this caused a problem. Simply, CDs and the CD reading mechanisms were not 100% faultless. That is, errors (indeed frequent errors) could be made during the reading. For audio CDs, this does not matter as much as you could simply interpolate from the adjacent audio samples. This will obviously NOT DO for data CDs. A single bit error could lead to a program being unexcitable or ruin an achieve file.
Thus, for CD-ROMs, part of each sector is devoted to error correction codes and error detection codes. The CD-R FAQ has the details, but in effect, only 2048 bytes out of a total of 2352 bytes in each sector is available for user data on a data CD.
This burning mode is either MODE1 or MODE2 Form1.
6ft Digital Optical TOSLink Fiber-Optic AUDIO Cable (black) for DVD / CD / Xbox / ALESIS / Sony Playstation 2 (100-pack LOT)

MODE2 Form2 sectors of VCDs and SVCDs
Now, for VCDs and SVCDs, the video tracks do not necessarily require the robust error correction as normal data on a CD-ROM. However, there is still some overhead per sector that is used for something other than video data (e.g., sync headers).
S/VCDs video tracks are burnt in what is called MODE2 Form2 sectors. In this mode, only 2324 bytes out of a total of 2352 bytes in each sector is available for user data. Sony BDP-S580 Blu-Ray Disc Player (Black)Sony BDP-S470 3D Blu-ray Disc Player
This is MUCH MORE than for CD-ROMs, but still less per sector than audio CD.
----------------------------------------------------------------
The disc capacities of CD-ROMs, audio-CDs and VCDs
Now, obviously what ultimately determines the capacity of a disc is the total number of sectors it contains. This is similar to the total number of pages in a blank exercise book (if you recall the book analogy).
The secondary determinant is the burning mode of the disc.
For audio CDs, it is as if you could fill each page from top to bottom with audio data as the entire sector is used for audio data.
For CD-ROMs, it is as if you need to first rule a margin and then leave the bottom part of each page for footnotes (headers + ECC + EDC). The amount of text you can actually write per page is then less due to these other constraints.
For S/VCDs, we still need to rule a margin on the page, but we don't have to worry about the footnotes (headers). We can fit MORE text than a CD-ROM, but less than an audio-CD.
Now remember, 1 second on a CD = 75 sectors.
Thus:
- 74 min CD = 333,000 sectors
- 80 min CD = 360,000 sectors
Data capacity in Mb for an audio-CD
74 minSony Bloggie Touch (MHS-TS20/B) - 8 GB, 4 Hours NEWEST MODEL (Black)Sony Bloggie Touch (MHS-TS20/S) - 8 GB, 4 Hours NEWEST MODEL (Silver)Search Amazon.com for sony bloggie touch
= 333,000 sectors * 2352 bytes / sector
= 783216000 bytes
= 746.9 Mb
80 min
= 360,000 sectors * 2352 bytes / sector
= 846720000 bytes
= 807.5 Mb
Data capacity in Mb for a CD-ROM
74 min
= 333,000 sectors * 2048 bytes / sector
= 681984000 bytes
= 650.4 Mb
80 min
= 360,000 sectors * 2048 bytes / sector
= 737280000 bytes
= 703.1 Mb
Data capacity in Mb for a S/VCD
74 min
= 333,000 sectors * 2324 bytes / sector
= 773892000 bytes
= 738.0 Mb
80 min
= 360,000 sectors * 2324 bytes / sector
= 836640000 bytes
= 797.9 Mb
Sony VAIO VPC-EB3AFX/BJ 15.5-Inch Laptop (Black) Apple MacBook Pro MC374LL/A 13.3-Inch LaptopApple MacBook Pro MC700LL/A 13.3-Inch Laptop
Conclusions
As you can see, the often quoted capacities of 650MB and 700MB refer to CD-ROM capacities.
Due to the fact that S/VCDs use a different burning mode where MORE of each sector is available as user data, the relatively capacities are HIGHER.
Now, since S/VCDs are not composed of PURELY video tracks and have some unavoidable overheads, the actually total capacity left for video tracks is a few Mb less for each disc (about 735 Mb for 74min discs and 795 Mb for 80min discs). This is where the often quoted capacities of 740MB and 800MBDell Inspiron 1545 15.6-Inch Laptop I1545-3232OBK (Obsidian Black), 2.3GHz Intel CPU; 2GB Memory; 250GB HD; DVD/CD±R/RW; Windows 7 Home Premium come from. They are quite accurate.
All these capacities are available BEFORE overburning. OveAcer Ferrari 3200 Laptop Computer PCrburning is where you burn MORE sectors than the disc is rated for. If you overburn, you can typically achieve about 1-2 minutes of additional capacity (depending on your drive and media).
